Ardupilot part3. Rover开发无人船及Loiter模式简述

#include "mode.h"
#include "Rover.h"

void ModeAcro::update()
{
    float desired_steering, desired_throttle;
    get_pilot_desired_steering_and_throttle(desired_steering, desired_throttle);

    // convert pilot throttle input to desired speed (up to twice the cruise speed)
    float target_speed = desired_throttle * 0.01f * calc_speed_max(g.speed_cruise, g.throttle_cruise * 0.01f);

    // get speed forward
    float speed;
    if (!attitude_control.get_forward_speed(speed)) {
        // no valid speed so stop
        g2.motors.set_throttle(0.0f);
        g2.motors.set_steering(0.0f);
        return;
    }

    // determine if pilot is requesting pivot turn
    bool is_pivot_turning = g2.motors.have_skid_steering() && is_zero(target_speed) && (!is_zero(desired_steering));

    // convert steering request to turn rate in radians/sec
    float turn_rate = (desired_steering / 4500.0f) * radians(g2.acro_turn_rate);

    // set reverse flag backing up
    bool reversed = is_negative(target_speed);
    rover.set_reverse(reversed);

    // run speed to throttle output controller
    if (is_zero(target_speed) && !is_pivot_turning) {
        stop_vehicle();
    } else {
        // run steering turn rate controller and throttle controller
        float steering_out = attitude_control.get_steering_out_rate(turn_rate, g2.motors.have_skid_steering(), g2.motors.limit.steer_left, g2.motors.limit.steer_right, reversed);
        g2.motors.set_steering(steering_out * 4500.0f);
        calc_throttle(target_speed, false);
    }
}

class ModeLoiter : public Mode
{
public:

    Number mode_number() const override { return Number::LOITER; }
    const char *name() const override { return "Loiter"; }
    const char *name4() const override { return "LOIT"; }

    // methods that affect movement of the vehicle in this mode
    void update() override;

    // attributes of the mode
    bool is_autopilot_mode() const override { return true; }

    // return desired heading (in degrees) and cross track error (in meters) for reporting to ground station (NAV_CONTROLLER_OUTPUT message)
    float wp_bearing() const override { return _desired_yaw_cd * 0.01f; }
    float nav_bearing() const override { return _desired_yaw_cd * 0.01f; }
    float crosstrack_error_m() const override { return 0.0f; }

    // return desired location
    bool get_desired_location(Location& destination) const override WARN_IF_UNUSED;

    // return straight-line distance (in meters) to destination
    float get_distance_to_destination() const override { return _distance_to_destination; }

protected:

    bool _enter() override;

    Location _destination;      // target location to hold position around
    float _desired_speed;       // desired speed (ramped down from initial speed to zero)
};

bool ModeLoiter::_enter()
{
    // set _destination to reasonable stopping point
    if (!g2.wp_nav.get_stopping_location(_destination)) {
        return false;
    }

    // initialise desired speed to current speed
    if (!attitude_control.get_forward_speed(_desired_speed)) {
        _desired_speed = 0.0f;
    }

    // initialise heading to current heading
    _desired_yaw_cd = ahrs.yaw_sensor;

    return true;
}

void ModeLoiter::update()
{
    // get distance (in meters) to destination
    _distance_to_destination = rover.current_loc.get_distance(_destination);

    const float loiter_radius = g2.sailboat.tack_enabled() ? g2.sailboat.get_loiter_radius() : g2.loit_radius;

    // if within loiter radius slew desired speed towards zero and use existing desired heading
    if (_distance_to_destination <= loiter_radius) {
        // sailboats should not stop unless motoring
        const float desired_speed_within_radius = g2.sailboat.tack_enabled() ? 0.1f : 0.0f;
        _desired_speed = attitude_control.get_desired_speed_accel_limited(desired_speed_within_radius, rover.G_Dt);

        // if we have a sail but not trying to use it then point into the wind
        if (!g2.sailboat.tack_enabled() && g2.sailboat.sail_enabled()) {
            _desired_yaw_cd = degrees(g2.windvane.get_true_wind_direction_rad()) * 100.0f;
        }
    } else {
        // P controller with hard-coded gain to convert distance to desired speed
        _desired_speed = MIN((_distance_to_destination - loiter_radius) * g2.loiter_speed_gain, g2.wp_nav.get_default_speed());

        // calculate bearing to destination
        _desired_yaw_cd = rover.current_loc.get_bearing_to(_destination);
        float yaw_error_cd = wrap_180_cd(_desired_yaw_cd - ahrs.yaw_sensor);
        // if destination is behind vehicle, reverse towards it
        if ((fabsf(yaw_error_cd) > 9000 && g2.loit_type == 0) || g2.loit_type == 2) {
            _desired_yaw_cd = wrap_180_cd(_desired_yaw_cd + 18000);
            yaw_error_cd = wrap_180_cd(_desired_yaw_cd - ahrs.yaw_sensor);
            _desired_speed = -_desired_speed;
        }

        // reduce desired speed if yaw_error is large
        // 45deg of error reduces speed to 75%, 90deg of error reduces speed to 50%
        float yaw_error_ratio = 1.0f - constrain_float(fabsf(yaw_error_cd / 9000.0f), 0.0f, 1.0f) * 0.5f;
        _desired_speed *= yaw_error_ratio;
    }

    // 0 turn rate is no limit
    float turn_rate = 0.0;

    // make sure sailboats don't try and sail directly into the wind
    if (g2.sailboat.use_indirect_route(_desired_yaw_cd)) {
        _desired_yaw_cd = g2.sailboat.calc_heading(_desired_yaw_cd);
        if (g2.sailboat.tacking()) {
            // use pivot turn rate for tacks
            turn_rate = g2.wp_nav.get_pivot_rate();
        }
    }

    // run steering and throttle controllers
    calc_steering_to_heading(_desired_yaw_cd, turn_rate);
    calc_throttle(_desired_speed, true);
}
